Features
3x64 DALI slave devices.
Provides benefits of DALI control & monitoring.
DALI bus short circuit protection.
LED indication of power, network, DALI.
Override on, off, dim buttons.
Downloads
The Prolojik PL330 range encapsulates the networking benefits of Prolojik’s lighting solutions and the installation benefits of DALI.
The Prolojik PL330 raises the DALI functionality to a new level, providing unparalleled device and control density.
The controllers can be configured for control of up to 3x64 DALI ballasts, DALI emergency inverters, DALI sensors, DALI scene setting plates or DALI switch interfaces.
Specifications
Features
250 mA drive per DALI bus.
3×64 DALI addresses.
Fully networked solution.
Fail-safe mode to occupied state.
LED indication for power, network, DALI.
Override on, off, dim buttons.
Networking
LonWorksTM network TP/FT-10 (Capacitor Decoupled).
Connections
Mains input.
L, E, N Screw Terminal connections.
DALI Bus.
D1, D2 screw terminal connections for each DALI bus.
Dimensions
355mm x 260mm x 80mm (L x W x H).
Override Buttons
Broadcast off.
Broadcast on.
Broadcast dim.
Safety
EN 60 950.
Isolation: 4kV between mains & outputs.
Conformity & Standards
EMC emissions: EN 61000-6-3.
EMC immunity: EN 61000-6-1.
RFI: EN 55 014.
LonMarkTM compliant.
DALI compliant.
Environment
Storage
Temperature: -10°C -+60°C.
Humidity: 0% -90% non-condensing.
In Use
Temperature:0°C -+40°C.
Humidity: 10% -90% non-condensing.
Mains Supply
100 230VAc, 47-63Hz.
5A unswitched fused spur (1A minimum).
Output
DALI bus output or outputs (for 64 DALI addresses each).
Output isolation: 4kV.
Connection: Rising clamp screw terminal.
