Features
Lighting controls system scheduler.
Browser based management interface.
Power, network and network traffic status indication.
Simple integration and wiring.
Fully distributed intelligence.
LAN / Intranet connection.
Laptop connection point.
Downloads
The PN510 is an IP router hub that allows for the connection of Prolojik LON networks to larger building management infrastructures. The PN510 offers a hugely flexible, feature packed area control device.
Specifications
LAN Connection
2 x RJ-45 jacks for WAN and LAN, including LON IP-70 and IP-852, BACnet/IP and Modbus TCP.
Default IP: 192.168.1.222.
Subnet mask: 255.255.255.0.
Homepage: http://<hostname>.local OR http://192.168.1.222.
Network
LonWorks™ network TP/FT-10 (Capacitor decoupled).
LonWorks™ Interoperable solution.
Cable cross sections from 0.5 to 2.5mm².
Beldon 8471 twisted pair unscreened or equivalent.
Network Inputs
2 x RJ45 Network inputs.
4 x USB Type A local IoT network and I/O interfaces.
1 x Micro-B USB console port.
Dimensions
140 mm x 89 mm x 65 mm (LxWxH).
Fixings
Spring retractive DIN rail mounting clip.
DIN 43880 8TEEN50022.
Safety
EN 61000-4-5:2006.
Conformity and Standards
FCC, CE, IC, and CCC.
EN55022 Class B.
EN55024.
Environment
Storage
Temperature: -40°c -+70°c.
In Use
Temperature: -40°c -+70°c.
Power Supply
10.5-30VDC, 10W or isolated 12-30VAC, 12VA, 50/60Hz.
